GLHF Golf
1 / 5
| KR-G Series Vehicle Parameter | ||||||||
| Vehicle Model | G2 | G2H | G2+2 | G2+2H | G4 | G4H | G4+2 | G4+2H |
| Load / Dimensions | ||||||||
| Curb Weight (excl. battery) | ≤390kg | ≤420kg | ≤460kg | ≤490kg | ≤420kg | ≤460kg | ≤490kg | ≤520kg |
| Seats | 2 | 2 | 4 | 4 | 4 | 4 | 6 | 6 |
| Body Dimensions | 2370*1340*2000mm | 2430*1340*2080mm | 2860*1340*2000mm | 2920*1340*2080mm | 3180*1340*2000mm | 3240*1340*2080mm | 3670*1340*2000mm | 3730*1340*2080mm |
| Front/Rear Track | Front 1030mm / Rear 1030mm | |||||||
| Wheelbase | 1675mm | 2420mm | ||||||
| Vehicle Performance | ||||||||
| Max Speed | ≤20MPH/Hours | ≤25MPH/Hours | ≤20MPH/Hours | ≤25MPH/Hours | ≤20MPH/Hours | ≤25MPH/Hours | ≤20MPH/Hours | ≤25MPH/Hours |
| Min Turning Radius | 4m | 4.5m | ||||||
| Braking Distance | <3m | <4.0m | ||||||
| Gradeability / Parking | 20% — 30% | |||||||
| Range | 60-80mile (Flat road) | |||||||
| Min Ground Clearance | 140mm | 190mm | 140mm | 190mm | 140mm | 190mm | 140mm | 190mm |
| Powertrain | ||||||||
| Motor | 48V5KW IP67 AC Motor (PMSM) (Upgradable to 72V5KW) | |||||||
| Controller | 48V/350A IP67 AC Controller, with CAN bus & Built-in Bluetooth | |||||||
| Battery | 51.2V105AH LiFePO4 Battery (incl. UL38.8, MSDS certifications, etc.) | |||||||
| Charger | Intelligent On-board Charger 48V/20A, Charging Time ≤5 hours | |||||||
| DC | High-power Isolated DC-DC Converter 48V/12V-500W | |||||||
| Body / Chassis | ||||||||
| Chassis | High-strength sheet metal beam w/ composite frame; Painting: Pickling + E-coating + Spray painting, Pillar fine sand texture | |||||||
| Body | Injection molded exterior (Metallic paint finish), Injection molded matte black roof | |||||||
| Flooring | Integrated molded PVC anti-aging floor vinyl | |||||||
| Seats | Integrated foam molded seat cushion + Premium microfiber leather; Leather embossed (striped) | |||||||
| Front Suspension | MacPherson independent front suspension + Coil spring + Tubular hydraulic shock absorber | |||||||
| Rear Suspension | Integral rear axle, Ratio 12.3:1 Coil spring + Tubular hydraulic shock absorber + Single swing arm + Stabilizer bar suspension | |||||||
| Braking System | Four-wheel hydraulic brake, Four-wheel disc brake + Electromagnetic parking brake (with vehicle towing function) | |||||||
| Steering System | Rack and pinion steering system, Automatic backlash compensation + EPS | |||||||
| Instrument Panel | Carbon fiber style (Hydro transfer printing) dashboard; IP66 premium 10-inch multimedia combo meter (Vehicle info + Multimedia) | |||||||
| Headlights | LED front combination lights (Low beam, High beam, Turn signal, DRL, Position light, Light bar) | |||||||
| Taillights | LED rear combination lights (Brake light, Position light, Turn signal) | |||||||
Estimated Transit Time: Approximately 8 weeks to arrive at your destination. We prioritize efficient logistics to ensure your order reaches you in a timely manner.
Delivery Time: Production Lead Time: Around 45 working days after receipt of the deposit. Our team works diligently to complete your order as quickly as possible without compromising on quality.
MOQ: Just 1 set. We understand that you may want to start with a smaller order, and we're happy to accommodate that.
Payment Terms: 30% T/T (Telegraphic Transfer) as a deposit to secure your order. The remaining 70% T/T is due before delivery. This ensures that both parties are satisfied with the arrangement and you can rest assured that your order is in safe hands.
Standard Warranty: 24 months
Extended Warranty: Optional coverage up to 36 months.
Global Support: Technical assistance and spare parts supply.
Training: On-site or remote operation/maintenance training.
Absolutely! Sample orders are readily available for quality checks and market testing. We understand the importance of verifying product quality before making larger commitments, and we're here to support you every step of the way.
Our standard production timeline is approximately 45 working days, based on the specifications and quantity of your order. We're committed to delivering your products on time without compromising on quality.
We primarily accept T/T (Telegraphic Transfer) or L/C at sight as our standard payment methods. However, we're open to discussing other payment options to ensure a mutually beneficial arrangement.
We offer varying warranty periods for different components to ensure your peace of mind. For detailed information, please feel free to contact us. We're always here to provide the support you need.
No, we don't keep stock on hand. Each product, including samples, is custom-produced according to your specific order. This ensures that you receive products tailored precisely to your requirements.
Yes, of course! You can mix different models in a single container to optimize your shipping and logistics. We're flexible and ready to accommodate your needs.
