| Technical Configurations & Parameters | |||
|---|---|---|---|
| Electric System | |||
| Controller | 1266/275A | ||
| Battery | Trojan battery 8V, 6 units | ||
| Motor | KDS 48V/3.7KW motor | ||
| Charger | Computer Intelligent input 220V/110V output 48V 20A | ||
| Charging Specifications | |||
| Charging Time | Less than 12 hours (discharging rate 80%) | ||
| Body Configuration | |||
| Glass | PC glass | Sun Roof | ABS Vacuum forming |
| Seat | Leather | Floor | Antiskid rubber floor |
| Rear Mirror | Hand operated, both sides | Steering | Dual automotive-style strut and self-adjust rack-and-pinion steering |
| DC/Light/Signal | 48V/12V-300W Front light, turning light, rear light, horn, buzzer | ||
| Body Material | PP Vacuum forming | ||
| Dash Board | PP Vacuum forming with Voltage Indicator 48V, Head Light Switch, Turn Indicators, Key Switch, and FWD/REV Switch | ||
| Braking System | Rear drum brake + compound pedal brake | ||
| Suspension (Front) | Independent suspension helical spring + cylinder hydraulic shock absorption | ||
| Suspension (Rear) | Integral type transaxle (gear ratio 12.31:1), semi-independent transaxle, spring, cylinder hydraulic shock absorption | ||
| Tire Diameter | 452mm | ||
| Parameters | |||
| Dimensions | 3320 * 1200 * 1900mm | ||
| Passenger Capacity | 6 Persons | ||
| Max Speed | 22 km/h | ||
| Driving Range | 80 - 90 km (flat road) | ||
| Max Climbing Ability | 20% | ||
| Min Turning Radius | 3.9m | ||
| Min Ground Clearance | 110mm | ||
| Wheel Base | Front 930 / Back 1010mm | ||
| Braking Distance | 4.4m | ||
